Proportional pressure reducing valves
ZDE3
Details
- Catalog: 81510
- Size: ISO 4401-03
- Mounting Style: subplate
- Max Operating Pressure: 100 bar
- Max Flow: 15 l/min
Download
- Rendering 3D: 3D Model
- * Data sheets:
- Other languages:
- * Last update: IT (05/02/2024)
DESCRIPTION
The ZDE3 is a proportional pressure reducing valve, direct operated, for subplate mounting. It is used to reduce pressure in the secondary circuit branches thus ensuring stability of controlled pressure in the event of variations of the flow rate through the valve. The valve can be controlled directly by a current-controlled power supply, or by an electronic card, to be order separately.
