Poppet valves solenoid actuated
DT03
Details
- Catalog: 42200
- Size: ISO 4401-03
- Mounting Style: subplate
- Max Operating Pressure: 250 bar
- Max Flow: 25 l/min
Download
- Rendering 3D: 3D Model
- * Data sheets:
- Other languages:
- * Last update: DE (07/03/2024)
DESCRIPTION
The DT03 are direct operated poppet valves with solenoid actuation. For subplate mounting. They are 2-ports and 3-ports design, with spring return. Double seal configuration available in two-port versions. The valves are available with DC solenoid or RAC solenoids to be feed with AC power supply. Connectors with built-in rectifier bridge are needed.
