Explosion-proof poppet valves, solenoid actuated compliant with ATEX, IECEx, INMETRO, PESO
DT3K*
DESCRIPTION
The DT3K* are direct operated poppet valves with solenoid actuation, explosion-proof. For subplate mounting. They are compliant with ATEX, IECEx, INMETRO or PESO requirements and are suitable for use in potentially explosive atmospheres, for surface plants or mines. A low temperature version (up to - 40 °C) is also available. Monobloc steel coil version is available. They are 3-ports, normally open or normally closed, with spring return. These valves apply in hydraulic circuit applications where leakage free is strictly required. The valves are available with DC solenoid or RAC solenoids to be feed with AC power supply. Rectifier bridge is built-in in the coil. Several connection types are available, metric or NPT type. Cable glands are available.
