Solenoid actuated directional control valve
DS5

  1. Home
  2. Products
  3. Directional Valves
  4. DS5

Details

  • Catalog: 41310
  • Size: ISO 4401-05
  • Mounting Style: subplate
  • Max Operating Pressure: 320 bar
  • Max Flow: 150 l/min

Download

  • Rendering 3D: 3D Model
  • * Data sheets: lan lan
  • Other languages: lanlan
  • * Last update: DE (21/06/2023)

DESCRIPTION

DS5 are spools directional valves that control passage and direction of a flow, for subplate mounting. They are available with 3-ports and 4-ports design, with spring return or mechanical detent. The valve body is made with high strength iron castings provided with wide internal passages in order to minimize the flow pressure drops. Wet armature solenoids with interchangeable coils are used. The valve is available with DC or AC solenoids. DC solenoids can also be fed with AC power supply, by using connectors with a built-in rectifier bridge. Alternative to the standard manual override there are knob, boot and mechanical detent device. The valve is available also with mounting interface with the Y port for external drain and with fixed or adjustable soft-shifting devices.
